파워그립GT풀리
파워그립GT풀리 5GT타입
게이츠유니타아시아(주) ( GATES UNITTA ASIA )
|
공통사양
캐드자료
카탈로그
|
|
관련이미지 | |
상세사양 |
|
302건 중 1~302건 표시 | |
형식 | 형상 | 잇수 | 벨트폭 (mm) | W (mm) | L (mm) | A (mm) | fb (mm) | 피치원직경 PD (mm) | 이끝원직경 OD (mm) |
P14-5GT-9-33F | 33F | 14 | 9 | 14 | 22 | 10.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-9-33F | 33F | 15 | 9 | 14 | 22 | 10.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-9-33F | 33F | 16 | 9 | 14 | 22 | 10.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-9-33F | 33F | 18 | 9 | 14 | 22 | 10.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-9-33F | 33F | 19 | 9 | 14 | 22 | 10.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-9-33F | 33F | 20 | 9 | 14 | 22 | 10.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-9-33F | 33F | 21 | 9 | 14 | 22 | 10.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-9-33F | 33F | 22 | 9 | 14 | 22 | 10.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-9-33F | 33F | 24 | 9 | 14 | 22 | 10.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-9-33F | 33F | 25 | 9 | 14 | 22 | 10.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-9-33F | 33F | 26 | 9 | 14 | 22 | 10.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-9-33F | 33F | 28 | 9 | 14 | 22 | 10.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-9-33F | 33F | 30 | 9 | 14 | 22 | 10.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-9-33F | 33F | 32 | 9 | 14 | 22 | 10.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-9-33F | 33F | 36 | 9 | 14 | 22 | 10.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-9-33F | 33F | 40 | 9 | 14 | 22 | 10.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-9-33F | 33F | 44 | 9 | 14 | 22 | 10.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-9-33F | 33F | 48 | 9 | 14 | 22 | 10.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-9-33F | 33F | 50 | 9 | 14 | 22 | 10.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-9-33F | 33F | 60 | 9 | 14 | 22 | 10.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-9-33F | 33F | 72 | 9 | 14 | 22 | 10.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-12-33F | 33F | 14 | 12 | 17 | 25 | 13.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-12-33F | 33F | 15 | 12 | 17 | 25 | 13.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-12-33F | 33F | 16 | 12 | 17 | 25 | 13.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-12-33F | 33F | 18 | 12 | 17 | 25 | 13.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-12-33F | 33F | 19 | 12 | 17 | 25 | 13.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-12-33F | 33F | 20 | 12 | 17 | 25 | 13.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-12-33F | 33F | 21 | 12 | 17 | 25 | 13.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-12-33F | 33F | 22 | 12 | 17 | 25 | 13.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-12-33F | 33F | 24 | 12 | 17 | 25 | 13.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-12-33F | 33F | 25 | 12 | 17 | 25 | 13.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-12-33F | 33F | 26 | 12 | 17 | 25 | 13.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-12-33F | 33F | 28 | 12 | 17 | 25 | 13.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-12-33F | 33F | 30 | 12 | 17 | 25 | 13.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-12-33F | 33F | 32 | 12 | 17 | 25 | 13.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-12-33F | 33F | 36 | 12 | 17 | 25 | 13.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-12-33F | 33F | 40 | 12 | 17 | 25 | 13.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-12-33F | 33F | 44 | 12 | 17 | 25 | 13.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-12-33F | 33F | 48 | 12 | 17 | 25 | 13.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-12-33F | 33F | 50 | 12 | 17 | 25 | 13.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-12-33F | 33F | 60 | 12 | 17 | 25 | 13.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-12-33F | 33F | 72 | 12 | 17 | 25 | 13.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-15-33F | 33F | 14 | 15 | 20 | 28 | 16.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-15-33F | 33F | 15 | 15 | 20 | 28 | 16.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-15-33F | 33F | 16 | 15 | 20 | 28 | 16.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-15-33F | 33F | 18 | 15 | 20 | 28 | 16.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-15-33F | 33F | 19 | 15 | 20 | 28 | 16.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-15-33F | 33F | 20 | 15 | 20 | 28 | 16.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-15-33F | 33F | 21 | 15 | 20 | 28 | 16.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-15-33F | 33F | 22 | 15 | 20 | 28 | 16.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-15-33F | 33F | 24 | 15 | 20 | 28 | 16.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-15-33F | 33F | 25 | 15 | 20 | 28 | 16.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-15-33F | 33F | 26 | 15 | 20 | 28 | 16.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-15-33F | 33F | 28 | 15 | 20 | 28 | 16.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-15-33F | 33F | 30 | 15 | 20 | 28 | 16.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-15-33F | 33F | 32 | 15 | 20 | 28 | 16.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-15-33F | 33F | 36 | 15 | 20 | 28 | 16.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-15-33F | 33F | 40 | 15 | 20 | 28 | 16.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-15-33F | 33F | 44 | 15 | 20 | 28 | 16.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-15-33F | 33F | 48 | 15 | 20 | 28 | 16.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-15-33F | 33F | 50 | 15 | 20 | 28 | 16.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-15-33F | 33F | 60 | 15 | 20 | 28 | 16.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-15-33F | 33F | 72 | 15 | 20 | 28 | 16.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-25-33F | 33F | 14 | 25 | 30 | 40 | 26.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-25-33F | 33F | 15 | 25 | 30 | 40 | 26.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-25-33F | 33F | 16 | 25 | 30 | 40 | 26.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-25-33F | 33F | 18 | 25 | 30 | 40 | 26.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-25-33F | 33F | 19 | 25 | 30 | 40 | 26.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-25-33F | 33F | 20 | 25 | 30 | 40 | 26.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-25-33F | 33F | 21 | 25 | 30 | 40 | 26.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-25-33F | 33F | 22 | 25 | 30 | 40 | 26.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-25-33F | 33F | 24 | 25 | 30 | 40 | 26.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-25-33F | 33F | 25 | 25 | 30 | 40 | 26.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-25-33F | 33F | 26 | 25 | 30 | 40 | 26.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-25-33F | 33F | 28 | 25 | 30 | 40 | 26.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-25-33F | 33F | 30 | 25 | 30 | 40 | 26.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-25-33F | 33F | 32 | 25 | 30 | 40 | 26.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-25-33F | 33F | 36 | 25 | 30 | 40 | 26.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-25-33F | 33F | 40 | 25 | 30 | 40 | 26.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-25-33F | 33F | 44 | 25 | 30 | 40 | 26.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-25-33F | 33F | 48 | 25 | 30 | 40 | 26.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-25-33F | 33F | 50 | 25 | 30 | 40 | 26.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-25-33F | 33F | 60 | 25 | 30 | 40 | 26.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-25-33F | 33F | 72 | 25 | 30 | 40 | 26.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-9-6F | 6F | 14 | 9 | 14 | 22 | 10.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-9-6F | 6F | 15 | 9 | 14 | 22 | 10.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-9-6F | 6F | 16 | 9 | 14 | 22 | 10.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-9-6F | 6F | 18 | 9 | 14 | 22 | 10.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-9-6F | 6F | 19 | 9 | 14 | 22 | 10.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-9-6F | 6F | 20 | 9 | 14 | 22 | 10.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-9-6F | 6F | 21 | 9 | 14 | 22 | 10.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-9-6F | 6F | 22 | 9 | 14 | 22 | 10.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-9-6F | 6F | 24 | 9 | 14 | 22 | 10.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-9-6F | 6F | 25 | 9 | 14 | 22 | 10.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-9-6F | 6F | 26 | 9 | 14 | 22 | 10.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-9-6F | 6F | 28 | 9 | 14 | 22 | 10.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-9-6F | 6F | 30 | 9 | 14 | 22 | 10.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-9-6F | 6F | 32 | 9 | 14 | 22 | 10.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-9-6F | 6F | 36 | 9 | 14 | 22 | 10.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-9-6F | 6F | 40 | 9 | 14 | 22 | 10.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-9-6F | 6F | 44 | 9 | 14 | 22 | 10.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-9-6F | 6F | 48 | 9 | 14 | 22 | 10.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-9-6F | 6F | 50 | 9 | 14 | 22 | 10.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-9-6F | 6F | 60 | 9 | 14 | 22 | 10.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-9-6F | 6F | 72 | 9 | 14 | 22 | 10.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-12-6F | 6F | 14 | 12 | 17 | 25 | 13.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-12-6F | 6F | 15 | 12 | 17 | 25 | 13.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-12-6F | 6F | 16 | 12 | 17 | 25 | 13.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-12-6F | 6F | 18 | 12 | 17 | 25 | 13.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-12-6F | 6F | 19 | 12 | 17 | 25 | 13.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-12-6F | 6F | 20 | 12 | 17 | 25 | 13.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-12-6F | 6F | 21 | 12 | 17 | 25 | 13.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-12-6F | 6F | 22 | 12 | 17 | 25 | 13.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-12-6F | 6F | 24 | 12 | 17 | 25 | 13.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-12-6F | 6F | 25 | 12 | 17 | 25 | 13.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-12-6F | 6F | 26 | 12 | 17 | 25 | 13.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-12-6F | 6F | 28 | 12 | 17 | 25 | 13.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-12-6F | 6F | 30 | 12 | 17 | 25 | 13.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-12-6F | 6F | 32 | 12 | 17 | 25 | 13.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-12-6F | 6F | 36 | 12 | 17 | 25 | 13.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-12-6F | 6F | 40 | 12 | 17 | 25 | 13.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-12-6F | 6F | 44 | 12 | 17 | 25 | 13.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-12-6F | 6F | 48 | 12 | 17 | 25 | 13.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-12-6F | 6F | 50 | 12 | 17 | 25 | 13.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-12-6F | 6F | 60 | 12 | 17 | 25 | 13.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-12-6F | 6F | 72 | 12 | 17 | 25 | 13.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-15-6F | 6F | 14 | 15 | 20 | 28 | 16.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-15-6F | 6F | 15 | 15 | 20 | 28 | 16.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-15-6F | 6F | 16 | 15 | 20 | 28 | 16.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-15-6F | 6F | 18 | 15 | 20 | 28 | 16.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-15-6F | 6F | 19 | 15 | 20 | 28 | 16.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-15-6F | 6F | 20 | 15 | 20 | 28 | 16.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-15-6F | 6F | 21 | 15 | 20 | 28 | 16.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-15-6F | 6F | 22 | 15 | 20 | 28 | 16.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-15-6F | 6F | 24 | 15 | 20 | 28 | 16.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-15-6F | 6F | 25 | 15 | 20 | 28 | 16.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-15-6F | 6F | 26 | 15 | 20 | 28 | 16.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-15-6F | 6F | 28 | 15 | 20 | 28 | 16.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-15-6F | 6F | 30 | 15 | 20 | 28 | 16.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-15-6F | 6F | 32 | 15 | 20 | 28 | 16.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-15-6F | 6F | 36 | 15 | 20 | 28 | 16.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-15-6F | 6F | 40 | 15 | 20 | 28 | 16.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-15-6F | 6F | 44 | 15 | 20 | 28 | 16.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-15-6F | 6F | 48 | 15 | 20 | 28 | 16.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-15-6F | 6F | 50 | 15 | 20 | 28 | 16.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-15-6F | 6F | 60 | 15 | 20 | 28 | 16.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-15-6F | 6F | 72 | 15 | 20 | 28 | 16.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-25-6F | 6F | 14 | 25 | 30 | 40 | 26.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-25-6F | 6F | 15 | 25 | 30 | 40 | 26.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-25-6F | 6F | 16 | 25 | 30 | 40 | 26.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-25-6F | 6F | 18 | 25 | 30 | 40 | 26.3 | 1.85 | 28.65 | 27.5 |
P19-5GT-25-6F | 6F | 19 | 25 | 30 | 40 | 26.3 | 1.85 | 30.24 | 29.1 |
P20-5GT-25-6F | 6F | 20 | 25 | 30 | 40 | 26.3 | 1.85 | 31.83 | 30.69 |
P21-5GT-25-6F | 6F | 21 | 25 | 30 | 40 | 26.3 | 1.85 | 33.42 | 32.28 |
P22-5GT-25-6F | 6F | 22 | 25 | 30 | 40 | 26.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-25-6F | 6F | 24 | 25 | 30 | 40 | 26.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-25-6F | 6F | 25 | 25 | 30 | 40 | 26.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-25-6F | 6F | 26 | 25 | 30 | 40 | 26.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-25-6F | 6F | 28 | 25 | 30 | 40 | 26.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-25-6F | 6F | 30 | 25 | 30 | 40 | 26.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-25-6F | 6F | 32 | 25 | 30 | 40 | 26.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-25-6F | 6F | 36 | 25 | 30 | 40 | 26.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-25-6F | 6F | 40 | 25 | 30 | 40 | 26.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-25-6F | 6F | 44 | 25 | 30 | 40 | 26.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-25-6F | 6F | 48 | 25 | 30 | 40 | 26.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-25-6F | 6F | 50 | 25 | 30 | 40 | 26.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-25-6F | 6F | 60 | 25 | 30 | 40 | 26.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-25-6F | 6F | 72 | 25 | 30 | 40 | 26.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-9-33F-AL | 33F | 14 | 9 | 14 | 22 | 10.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-9-33F-AL | 33F | 15 | 9 | 14 | 22 | 10.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-9-33F-AL | 33F | 16 | 9 | 14 | 22 | 10.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-9-33F-AL | 33F | 18 | 9 | 14 | 22 | 10.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-9-33F-AL | 33F | 20 | 9 | 14 | 22 | 10.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-9-33F-AL | 33F | 22 | 9 | 14 | 22 | 10.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-9-33F-AL | 33F | 24 | 9 | 14 | 22 | 10.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-9-33F-AL | 33F | 25 | 9 | 14 | 22 | 10.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-9-33F-AL | 33F | 26 | 9 | 14 | 22 | 10.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-9-33F-AL | 33F | 28 | 9 | 14 | 22 | 10.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-9-33F-AL | 33F | 30 | 9 | 14 | 22 | 10.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-9-33F-AL | 33F | 32 | 9 | 14 | 22 | 10.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-9-33F-AL | 33F | 36 | 9 | 14 | 22 | 10.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-9-33F-AL | 33F | 40 | 9 | 14 | 22 | 10.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-9-33F-AL | 33F | 44 | 9 | 14 | 22 | 10.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-9-33F-AL | 33F | 48 | 9 | 14 | 22 | 10.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-9-33F-AL | 33F | 50 | 9 | 14 | 22 | 10.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-9-33F-AL | 33F | 60 | 9 | 14 | 22 | 10.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-9-33F-AL | 33F | 72 | 9 | 14 | 22 | 10.3 | 1.85 | 114.59 | 113.45 |
P14-5GT-12-33F-AL | 33F | 14 | 12 | 17 | 25 | 13.3 | 1.85 | 22.28 | 21.14 |
P15-5GT-12-33F-AL | 33F | 15 | 12 | 17 | 25 | 13.3 | 1.85 | 23.87 | 22.73 |
P16-5GT-12-33F-AL | 33F | 16 | 12 | 17 | 25 | 13.3 | 1.85 | 25.46 | 24.32 |
P18-5GT-12-33F-AL | 33F | 18 | 12 | 17 | 25 | 13.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-12-33F-AL | 33F | 20 | 12 | 17 | 25 | 13.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-12-33F-AL | 33F | 22 | 12 | 17 | 25 | 13.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-12-33F-AL | 33F | 24 | 12 | 17 | 25 | 13.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-12-33F-AL | 33F | 25 | 12 | 17 | 25 | 13.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-12-33F-AL | 33F | 26 | 12 | 17 | 25 | 13.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-12-33F-AL | 33F | 28 | 12 | 17 | 25 | 13.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-12-33F-AL | 33F | 30 | 12 | 17 | 25 | 13.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-12-33F-AL | 33F | 32 | 12 | 17 | 25 | 13.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-12-33F-AL | 33F | 36 | 12 | 17 | 25 | 13.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-12-33F-AL | 33F | 40 | 12 | 17 | 25 | 13.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-12-33F-AL | 33F | 44 | 12 | 17 | 25 | 13.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-12-33F-AL | 33F | 48 | 12 | 17 | 25 | 13.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-12-33F-AL | 33F | 50 | 12 | 17 | 25 | 13.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-12-33F-AL | 33F | 60 | 12 | 17 | 25 | 13.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-12-33F-AL | 33F | 72 | 12 | 17 | 25 | 13.3 | 1.85 | 114.59 | 113.45 |
P18-5GT-15-33F-AL | 33F | 18 | 15 | 20 | 28 | 16.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-15-33F-AL | 33F | 20 | 15 | 20 | 28 | 16.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-15-33F-AL | 33F | 22 | 15 | 20 | 28 | 16.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-15-33F-AL | 33F | 24 | 15 | 20 | 28 | 16.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-15-33F-AL | 33F | 25 | 15 | 20 | 28 | 16.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-15-33F-AL | 33F | 26 | 15 | 20 | 28 | 16.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-15-33F-AL | 33F | 28 | 15 | 20 | 28 | 16.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-15-33F-AL | 33F | 30 | 15 | 20 | 28 | 16.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-15-33F-AL | 33F | 32 | 15 | 20 | 28 | 16.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-15-33F-AL | 33F | 36 | 15 | 20 | 28 | 16.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-15-33F-AL | 33F | 40 | 15 | 20 | 28 | 16.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-15-33F-AL | 33F | 44 | 15 | 20 | 28 | 16.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-15-33F-AL | 33F | 48 | 15 | 20 | 28 | 16.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-15-33F-AL | 33F | 50 | 15 | 20 | 28 | 16.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-15-33F-AL | 33F | 60 | 15 | 20 | 28 | 16.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-15-33F-AL | 33F | 72 | 15 | 20 | 28 | 16.3 | 1.85 | 114.59 | 113.45 |
P18-5GT-25-33F-AL | 33F | 18 | 25 | 30 | 40 | 26.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-25-33F-AL | 33F | 20 | 25 | 30 | 40 | 26.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-25-33F-AL | 33F | 22 | 25 | 30 | 40 | 26.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-25-33F-AL | 33F | 24 | 25 | 30 | 40 | 26.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-25-33F-AL | 33F | 25 | 25 | 30 | 40 | 26.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-25-33F-AL | 33F | 26 | 25 | 30 | 40 | 26.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-25-33F-AL | 33F | 28 | 25 | 30 | 40 | 26.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-25-33F-AL | 33F | 30 | 25 | 30 | 40 | 26.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-25-33F-AL | 33F | 32 | 25 | 30 | 40 | 26.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-25-33F-AL | 33F | 36 | 25 | 30 | 40 | 26.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-25-33F-AL | 33F | 40 | 25 | 30 | 40 | 26.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-25-33F-AL | 33F | 44 | 25 | 30 | 40 | 26.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-25-33F-AL | 33F | 48 | 25 | 30 | 40 | 26.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-25-33F-AL | 33F | 50 | 25 | 30 | 40 | 26.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-25-33F-AL | 33F | 60 | 25 | 30 | 40 | 26.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-25-33F-AL | 33F | 72 | 25 | 30 | 40 | 26.3 | 1.85 | 114.59 | 113.45 |
P18-5GT-9-6F-AL | 6F | 18 | 9 | 14 | 22 | 10.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-9-6F-AL | 6F | 20 | 9 | 14 | 22 | 10.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-9-6F-AL | 6F | 22 | 9 | 14 | 22 | 10.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-9-6F-AL | 6F | 24 | 9 | 14 | 22 | 10.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-9-6F-AL | 6F | 25 | 9 | 14 | 22 | 10.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-9-6F-AL | 6F | 26 | 9 | 14 | 22 | 10.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-9-6F-AL | 6F | 28 | 9 | 14 | 22 | 10.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-9-6F-AL | 6F | 30 | 9 | 14 | 22 | 10.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-9-6F-AL | 6F | 32 | 9 | 14 | 22 | 10.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-9-6F-AL | 6F | 36 | 9 | 14 | 22 | 10.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-9-6F-AL | 6F | 40 | 9 | 14 | 22 | 10.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-9-6F-AL | 6F | 44 | 9 | 14 | 22 | 10.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-9-6F-AL | 6F | 48 | 9 | 14 | 22 | 10.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-9-6F-AL | 6F | 50 | 9 | 14 | 22 | 10.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-9-6F-AL | 6F | 60 | 9 | 14 | 22 | 10.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-9-6F-AL | 6F | 72 | 9 | 14 | 22 | 10.3 | 1.85 | 114.59 | 113.45 |
P18-5GT-12-6F-AL | 6F | 18 | 12 | 17 | 25 | 13.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-12-6F-AL | 6F | 20 | 12 | 17 | 25 | 13.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-12-6F-AL | 6F | 22 | 12 | 17 | 25 | 13.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-12-6F-AL | 6F | 24 | 12 | 17 | 25 | 13.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-12-6F-AL | 6F | 25 | 12 | 17 | 25 | 13.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-12-6F-AL | 6F | 26 | 12 | 17 | 25 | 13.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-12-6F-AL | 6F | 28 | 12 | 17 | 25 | 13.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-12-6F-AL | 6F | 30 | 12 | 17 | 25 | 13.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-12-6F-AL | 6F | 32 | 12 | 17 | 25 | 13.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-12-6F-AL | 6F | 36 | 12 | 17 | 25 | 13.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-12-6F-AL | 6F | 40 | 12 | 17 | 25 | 13.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-12-6F-AL | 6F | 44 | 12 | 17 | 25 | 13.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-12-6F-AL | 6F | 48 | 12 | 17 | 25 | 13.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-12-6F-AL | 6F | 50 | 12 | 17 | 25 | 13.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-12-6F-AL | 6F | 60 | 12 | 17 | 25 | 13.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-12-6F-AL | 6F | 72 | 12 | 17 | 25 | 13.3 | 1.85 | 114.59 | 113.45 |
P18-5GT-15-6F-AL | 6F | 18 | 15 | 20 | 28 | 16.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-15-6F-AL | 6F | 20 | 15 | 20 | 28 | 16.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-15-6F-AL | 6F | 22 | 15 | 20 | 28 | 16.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-15-6F-AL | 6F | 24 | 15 | 20 | 28 | 16.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-15-6F-AL | 6F | 25 | 15 | 20 | 28 | 16.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-15-6F-AL | 6F | 26 | 15 | 20 | 28 | 16.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-15-6F-AL | 6F | 28 | 15 | 20 | 28 | 16.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-15-6F-AL | 6F | 30 | 15 | 20 | 28 | 16.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-15-6F-AL | 6F | 32 | 15 | 20 | 28 | 16.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-15-6F-AL | 6F | 36 | 15 | 20 | 28 | 16.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-15-6F-AL | 6F | 40 | 15 | 20 | 28 | 16.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-15-6F-AL | 6F | 44 | 15 | 20 | 28 | 16.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-15-6F-AL | 6F | 48 | 15 | 20 | 28 | 16.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-15-6F-AL | 6F | 50 | 15 | 20 | 28 | 16.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-15-6F-AL | 6F | 60 | 15 | 20 | 28 | 16.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-15-6F-AL | 6F | 72 | 15 | 20 | 28 | 16.3 | 1.85 | 114.59 | 113.45 |
P18-5GT-25-6F-AL | 6F | 18 | 25 | 30 | 40 | 26.3 | 1.85 | 28.65 | 27.5 |
P20-5GT-25-6F-AL | 6F | 20 | 25 | 30 | 40 | 26.3 | 1.85 | 31.83 | 30.69 |
P22-5GT-25-6F-AL | 6F | 22 | 25 | 30 | 40 | 26.3 | 1.85 | 35.01 | 33.87 |
P24-5GT-25-6F-AL | 6F | 24 | 25 | 30 | 40 | 26.3 | 1.85 | 38.2 | 37.05 |
P25-5GT-25-6F-AL | 6F | 25 | 25 | 30 | 40 | 26.3 | 1.85 | 39.79 | 38.65 |
P26-5GT-25-6F-AL | 6F | 26 | 25 | 30 | 40 | 26.3 | 1.85 | 41.38 | 40.24 |
P28-5GT-25-6F-AL | 6F | 28 | 25 | 30 | 40 | 26.3 | 1.85 | 44.56 | 43.42 |
P30-5GT-25-6F-AL | 6F | 30 | 25 | 30 | 40 | 26.3 | 1.85 | 47.75 | 46.6 |
P32-5GT-25-6F-AL | 6F | 32 | 25 | 30 | 40 | 26.3 | 1.85 | 50.93 | 49.79 |
P36-5GT-25-6F-AL | 6F | 36 | 25 | 30 | 40 | 26.3 | 1.85 | 57.3 | 56.15 |
P40-5GT-25-6F-AL | 6F | 40 | 25 | 30 | 40 | 26.3 | 1.85 | 63.66 | 62.52 |
P44-5GT-25-6F-AL | 6F | 44 | 25 | 30 | 40 | 26.3 | 1.85 | 70.03 | 68.89 |
P48-5GT-25-6F-AL | 6F | 48 | 25 | 30 | 40 | 26.3 | 1.85 | 76.39 | 75.25 |
P50-5GT-25-6F-AL | 6F | 50 | 25 | 30 | 40 | 26.3 | 1.85 | 79.58 | 78.43 |
P60-5GT-25-6F-AL | 6F | 60 | 25 | 30 | 40 | 26.3 | 1.85 | 95.49 | 94.35 |
P72-5GT-25-6F-AL | 6F | 72 | 25 | 30 | 40 | 26.3 | 1.85 | 114.59 | 113.45 |
![]() |
- 아린재고가 있는 상품은 결재가 완료되면 결재한 다음날부터 1~3일 이내 전국(도서지방제외)으로 택배를 통해 배송됩니다. - 아린재고가 없는 수입품의 경우는 납품까지 수일 내지 수주가 소요될 수 있으므로 주문전에 당사에 납기를 미리 확인하여 주십시오. - 제품크기에 따라 택배나 화물운송업체를 통해 배송해 드리며, 주문금액 20만원 이하의 경우 5,500원의 배송비가 추가됩니다. - 제주도 등 도서지역의 경우 추가배송 금액이 발생할 수 있으니 주문전에 고객센터로 문의 주십시오.
|
![]() |
- 제품을 받아보시고 이상이 있을 경우에 한하여 배송 후 14일 이내에 교환 및 반품이 가능합니다. - 상품대금을 신용카드로 결제한 경우는 매출을 취소해드리며, 온라인으로 입금한 경우에는 주문자의 계좌번호로 3일내로 입금 처리해 드립니다. |
